Input Voltage

16VAC/75VA, Class 2

Dimensions (H.W.D)

11-3/4” x 11-3/8” x 3”

Operating temperature

From 2°C to 40°C (35°F to 110°F)

Reader types

Weigand, proximity, bar code, magnetic, integrated keypad

Monitor input zones

16 monitored input zones, NO/NC, with or without single or double end-of-line resistors

Door strike output

12VDC @ 250mA, supervised

Reader power output

5VDC and 12VDC @ 175mA

Auxiliary outputs

2 outputs, open NPN (LED, Buzzer)

Relay outputs

4 dry relays controlled output.

Communication port

RS-232, RS-485, Ethernet, SPI

Backup battery

1 lithium battery, up to 75 hours retention (data and RTC operation).

Certification/Listing

UL294, CE, FCC Part 15, Class B
